Processor / System Bus
1 x Socket SP3 (LGA 4094)
3rd Gen AMD EPYC™ processors with AMD 3D V-Cache™ technology
AMD EPYC™ 7003 Series
AMD EPYC™ 7002 Series -
Generation
E11 -
Memory
Total Slots :
16 (8-channel)
Capacity :
Maximum up to 4096GB RDIMM
Memory Type :
DDR4 3200/2933 RDIMM
DDR4 3200/2933 LRDIMM
DDR4 3200/2933 LR-DIMM 3DS
Memory Size :
128GB, 64GB, 32GB, 16GB RDIMM
128GB, 64GB LRDIMM
256GB, 128GB, 64GB LR-DIMM 3DS
* Refer to support page for more information -
Expansion Slots
2 x PCIe x16 slot(Gen4 x16 link, FHFL) or dual-slot GPU cards or 4 x PCIe x16 slot(Gen4 x8 link, FHFL)
1 x PCIe x16 slot(Gen4 x8 link, LP)
1 x OCP 3.0 Mezzanine slot -
Storage
Storage Controller :
CPU Integrated
SAS Controller :
Broadcom MegaRAID 9560-16i(Optional)
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card(Optional)
ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card(Optional) -
Drive Bays
24 x 2.5” hot-swap drive bays(24x U.2/U.3 NVMe or 16x U.2/U.3 NVMe + 8x SATA/SAS or 12x U.2/U.3 NVMe + 12x SATA/SAS)2 x M.2 connector (NGFF 22110/2280/2260/2242. SATA 6Gb/s*2 or PCIe Gen4 x4 link*1 or PCIe Gen4 x2 link*2)*SAS support only from SAS HBA/RAID Card*If supporting 24x NVMe, only 1x PCIe Gen4 x8 could use. -
System Fan
4 (if choose redundant fan, total:8) -
Networking
1 x Dual Port Intel I350-AM2 Gigabit LAN controller + 1 x Mgmt LAN -
Graphic
Aspeed AST2600 with 64MB VRAM -
Front I/O Ports
2 x USB 3.2 Gen1 ports -
Rear I/O Ports
2 x USB 3.2 Gen1 port
1 x VGA port
1 x Management port (RJ45)
2 x Gigabit LAN ports (RJ45) -
Switch/LED
Front Switch/LED:
1 x Power switch (w/LED)
1 x Reset Switch
1 x Location Switch (w/LED)
1 x HDD Access LED
1 x Message LED
LAN 1-2 LED
Rear Switch/LED:
1 x Power switch w/LED
1 x Port 80 LED(Q-Code)
1 x Location Switch w/LED
1 x Message LED -
OS Support
Please find the latest OS support from https://servers.asus.com/support/os -
Management Solution
ASUS Control Center Enterprise (Optional)
On-Board ASMB10-iKVM for KVM-over-IP -
Regulatory Compliance
BSMI, CE, RCM, FCC(Class A) -
Dimensions
840mm x 449mm x 88.1mm (33.07" x 17.68" x 3.47") -
Form Factor
2U -
Weight
Net Weight : 19.15KG Gross Weight : 28.74KG -
Power Supply
1+1 Redundant 800W 80 PLUS Platinum Power Supply Rating: 100-127 / 200-240Vac, 10A / 5A (for each inlet), 50-60Hz, Class I
1+1 Redundant 1600W 80 PLUS Titanium Power Supply
1+1 Redundant 1200W/1600W 80 PLUS Platinum Power Supply
Rating: 100-127 / 200-240Vac, 10A / 8A (for each inlet), 50-60Hz or 240Vdc, 6A
240Vdc Only for China -
Environment
Operation temperature: 10℃ ~ 35℃
Non operation temperature: -40℃ ~ 60℃
Non operation humidity: 20% ~ 90% (Non condensing) -
CPU Heatsink/ Cooler
1
