Processor / System Bus
2 x Socket SP3 (LGA 4094)
AMD EPYC™ 7003 Series
AMD EPYC™ 7002 Series
Max TDP : 280W
3rd Gen AMD EPYC™ processors with AMD 3D V-Cache™ technology -
Generation
E11 -
Memory
Total Slots :
32 (8-channel per CPU, 16 DIMM per CPU) per Node
Capacity :
Maximum up to 4096GB per socket
Memory Type :
Dual Channel DDR4 3200/2933 RDIMM
Dual Channel 3200/2933 LRDIMM
Dual Channel 3200/2933 LR-DIMM 3DS non ECC
Memory Size :
64GB, 32GB, 16GB RDIMM
128GB, 64GB LRDIMM
256GB, 128GB, 64GB LR-DIMM 3DS
* Refer to support page for more information -
Expansion Slots
Up to 3 x Expansion slots + 1 x Internal PIKE slot 1 x PCIe Gen4 x16, FHFL (CPU1) 1 x PCIe Gen4 x16, FHFL or OCP3.0 (CPU2) 1 x PCIe Gen4 x8 or x16, LP (if PCIe M.2 in use, it will operate at x8 link) (CPU2) *Installing GPU cards will occupied expansion slots. -
Storage
Storage Controller :
4 x SATA3 6Gb/s ports (SATA 6Gb/s & PCIe® Gen4 x4 link)
2 x M.2 connector(2242/2260/2280/22110) both SATA & PCIe mode
SAS Controller :
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card(Optional)
ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card(Optional)
Broadcom MegaRAID 9560-16i (Optional) -
Drive Bays
4 x 3.5" hot-swap drive bays (4 x NVMe/SATA/SAS*)
2 x M.2 (support SATA/PCIe M.2) (up to 22110) (CPU2) *must with PIKE/RAID card -
System Fan
8 -
Networking
1 x Quad Port Intel I350-AM4 1G LAN Controller + 1 x Mgmt LAN
or
Option 2
1 x Dual Port Intel X710-AT2 Gigabit 10G LAN Controller + 1 x Mgmt LAN
or
None x + 1 x Mgmt LAN -
Graphic
Aspeed AST2600 with 64MB VRAM -
Multi-GPU Support
Please find the latest GPU support from https://servers.asus.com/support/gpu -
Front I/O Ports
2 x USB 3.2 Gen1 ports 1 x VGA port -
Rear I/O Ports
2 x USB 3.2 Gen1 ports
1 x VGA port
1 x RJ-45 Mgmt LAN port
1 x OCP3.0 port (Please remember to insert OCP3.0 Board) -
Switch/LED
Front Switch/LED:
1 x Power switch (w/LED)
1 x Reset Switch
1 x Location Switch (w/LED)
1 x HDD Access LED
1 x Message LED LAN 1-4 LED (on NIC Module)
Rear Switch/LED:
1 x Power switch w/LED
1 x Port 80 LED(Q-Code)
1 x Location Switch w/LED
1 x Message LED -
OS Support
Please find the latest OS support from https://servers.asus.com/support/os -
Management Solution
On-Board ASMB10-iKVM for KVM-over-IP ASUS Control Center Enterprise (Optional) -
Regulatory Compliance
BSMI, CE, FCC(Class A) -
Dimensions
842.5mm x 449mm x 43.85mm (33.17" x 17.68" x 1.73") -
Form Factor
1U -
Weight
Net Weight : 18.85KG Gross Weight : 23.89KG -
Power Supply
1+1 Redundant 1200W/1600W 80 PLUS Platinum Power Supply Rating: 100-127/200-240Vac,9.4A/4.72A (x2) ,50/60Hz Class I (240Vdc, 4.6A Only for China) *1600W RPSU is required while choosing GPU SKU -
Environment
Operation temperature: 10℃ ~ 35℃
Non operation temperature: -40℃ ~ 60℃
Non operation humidity: 20% ~ 90% (Non condensing) -
Optional Items
Standard Cooling Solution or Water Cooling Solution -
Note
If only 1 CPU is installed, some functions might be not available. *SAS support only from SAS HBA/RAID Card
Merk | Asus |
---|---|
Style | Bisnis |
Platform | Rackmount Server |
Prosesor | AMD EPYC |
RAM | 64GB |
Storage | 4TB |
Display | - |
Display Type | - |
OS | DOS |
VGA | Integrated |
I/O | LAN RJ 45 |
Garansi | 3 Tahun |
