Processor / System Bus
2 x Socket P (LGA 3647)1st and 2nd Gen Xeon® Scalable Processor Family*Refer to support page for more informationUPI (10.4 GT/s) -
Generation
E9 -
Core Logic
Intel® C621 Chipset4 GT/s) -
Memory
Total Slots : 24 (6-channel per CPU, 12 DIMM per CPU)Capacity :Up to 3TB (128Gx24) of memory for RDIMM/LRDIMMUp to 7.68TB (512G*12 DCPMM + 128G*12 RDIMM/LRDIMM)Memory Type :DDR4 2933/2666 RDIMMDDR4 2933/2666 LRDIMMDDR4 2933/2666 LR-DIMM 3DSIntel® Optane™ DC Persistent MemoryMemory Size :32GB, 16GB, 8GB, 4GB RDIMM64GB, 32GB LRDIMM128GB, 64GB LR-DIMM 3DS512GB, 256GB, 128GBIntel® Optane™ DC Persistent Memory* Refer to support page for more information* Actual memory frequency differs from Intel CPU types and memory module.Please check Intel official site for more detail about the memory types supported by each CPU.* Intel® Optane™ DC Persistent Memory for 2nd Generation Intel -
Expansion Slots
2 x PCI-E x16 (Gen3 x8 link) or 1 PCI-E x16 (Gen3 x16 link), FH, HL (CPU1)4 x PCI-E x16 (Gen3 x8 link) or 2 PCI-E x16 (Gen3 x16 link), FH, HL (CPU2)1 x PCI-E x16 (Gen3 x16 link), LP, HL (CPU2)1 x PCI-E x16 (Gen3 x8 link), FH, HL (CPU1)1 x OCP 2.0 Mezzanine (Gen3 x16 link) (CPU1)1 Chipset4 GT/s) -
Storage
SATA Controller :Intel® C621Intel® Rapid Storage Technology Enterprise(RSTe) (For Linux/Windows)(Support Software RAID 0, 1, 5, 10 )Intel®VROC (For Linux/Windows)(Support Software RAID 0/1/5/10 )SAS Controller :ASUS PIKE II 3008 8-port SAS HBA card(Optional)ASUS PIKE II 3108 8-port SAS HW RAID card(Optional)12G SAS Support 2.0 Mezzanine (Gen3 x16 link) (CPU1)1 Chipset4 GT/s) -
Drive Bays
Front bays:8 x 3.5" or 2.5" Hot-swap Storage Device Bays(4x SATA/SAS + 4x SATA/SAS/NVMe)2 x M.2 (22110, 2280, 2260, 2242)(Support SATA/PCIe M.2,SATA RAID) -
Networking
1 x Dual Port Intel Ethernet Controller i350-AM2 + 1 x Mgmt LAN -
Graphic
Aspeed AST2500 with 64MB VRAM -
Front I/O Ports
2 x USB 2.0 ports1 x VGA port -
Rear I/O Ports
2 x USB 3.0 ports1 x VGA port2 x RJ-45 GbE LAN ports1 x RJ-45 Mgmt LAN port -
Switch/LED
Rear Switch/LED:1 x Power switch1 x Q-Code/Port 80 LED1xMessage LED1xHDD LED1x Location LEDFront Switch/LED:1 x Power switch/LED1 x Location switch/LED1 x Reset switch1 x HDD Access LED1 x Message LEDLAN 1-4 LED* LAN3-4 for Mezzazine card use -
OS Support
Please find the latest OS support from https://servers.asus.com/support/os -
Management Solution
ASUS Control Center Enterprise (Optional)On-Board ASMB9-iKVM for KVM-over-IP -
Regulatory Compliance
BSMI, CE, FCC(Class A) -
Dimensions
750mm x 444mm x 88mm29.52" x 17.48" x 3.46" -
Form Factor
2U -
Weight
Net Weight 15.98kgGross Weight 23.25kg -
Power Supply
1+1 Redundant or 1+0800W 80 PLUS Platinum Power Supply850W 80 PLUS Titanium Power SupplyRating: 100-127Vac/200-240Vac,10A/5A ,50/60Hz, Class I(240Vdc Only for China) -
Environment
Operation temperature: 10℃ ~ 35℃Non operation temperature: -40℃ ~ 60℃Non operation humidity: 20% ~ 90% (Non condensing)
Merk | Asus |
---|---|
Style | Bisnis |
Platform | Rackmount Server |
Prosesor | Intel Xeon |
RAM | 64GB |
Storage | 4TB |
Display | - |
Display Type | - |
OS | DOS |
VGA | Integrated |
I/O | LAN RJ 45 |
Garansi | 3 Tahun |
