Compatible Peephole Diameter 16.5 ~ 50 mm (0.65 ~ 1.97 inch)
Compatible Door Thickness 35 ~ 105 mm (1.38 ~ 4.13 inch)
Camera
Sensor 1/3" Progressive Scan CMOS
Lens 2.2mm @ F2.4, view angle: 104° (horizontal / vertical), 136° (diagonal)
Day / Night Switch ICR infrared filter
IR Distance Max. 3 m (10ft.)
Max. Resolution 720P / 1MP
PIR Detection
Angle 100°
Distance Max. 3 m (10ft.)
Sensitivity Adjustable
Interface
Storage Interface MicroSD card slot supports up to 128 GB
Audio Input Built-in highly sensitive microphone
Audio Output Built-in high-power speaker
Buttons Doorbell button, power button, Screen wake up button
Network
Face Detection Supports
Intelligence Alarm PIR person detection
Protocol EZVIZ cloud proprietary protocol
Video Intercom Local and remote video intercom
General Function Cloud video encryption and image encryption
Wireless
Wi-Fi Standard IEEE802. 11b/g/n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11 Mbps, 11g: 54 Mbps, 11n: 144 Mbps
General
Screen 4.3” Color Screen
Color Silver
Operating Conditions -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
Power Supply DC 5V (±10%)
Power Consumption Max 2.2W
Dimension Screen and base: 115.5 x 85.5 x 24.5 mm (4.55 x 3.37 x 0.96 inch) Camera: 71 x 71 x 48.3 mm (2.80 x 2.80 x 1.90 inch)
Packaging Dimensions 165 x 107 x 80 mm (6.50 x 4.21 x 3.15 inch)
Weight 343 g (12.1 oz)
Merk | Ezviz |
---|
